Servo Motor Control System
"2KVA To 300 KVA"
We offer to our clients a high quality range of Servo A.C Voltage Stabilizer that offers high utility and effective performance. Our range of Servo Voltage Stabilizer is ideal for maintaining a continuous and stable supply of A.C. power to electronic systems.
Electroways voltage stabilizers with Toroid’s core technology in particular, use 100% copper wire and special silicon sheet for extremely low line losses. The modern roller carbon brushes help to run smooth, quick response, good cooling, limitless durability. Large scale production systems, modern test equipments, quality management according to ISO 9001: 2008. It can use in the harshest power. It is the result of 15 years of research, production, and continuous improvement. The experience and technological know-how has created the product durability, reliability and savings best meet the demands of field.
The servo voltage stabilizers have been designed for hard conditions. The voltage stabilizers can be produced with different features for your needs. The servo voltage stabilizer produced for protection from lighting, high voltage drops, high voltages, flickers and if needed harmonics as well.
* Factory, hospital, hotel and apartment building main entrances.
* And other places where stable voltage is required.
* Magnetic devices. illuminating devices.
* Sensitive photograph studio equipment and devices.
* Electroplating equipment.
* CNC machine tools. heating, cooling air-conditioning equipment.
* All kinds of electronic embroidery weaving looms.
* Data centers
* Industrial zones
* Wired and wireless communication devices.
* Automatic welding machines.
* Modern industrial equipment.
|
TECHNICAL SPECIFICATIONS |
|
|
Electroways 3
phase voltage stabilizers regulate mains
voltage and brings many advantages. » Power Range 2-100 KVA » 3 phase input 3 phase output » Wide power and voltage interval » Fast Regulation » High reliability and Smart Driver » High efficiency » Safe and economic usage » Over current and overload protection (Optional) » Analog displayed status, input & output measurements » 1 years warranty |
Electroways 1
Phase Voltage stabilizer are D.C motor drive
structure, heavy duty devices which
regulates mains voltage for critical loads.
All the stabilizers with electronic controls have 1 year warranty against production and technical defects. All the materials used in the regulators have high quality standard. » Power Range 2-100 KVA » High reliability and Smart Driver » High efficiency » Safe and economic usage » Over current and overload protection (Optional) » Analog displayed status, input & output measurements » 1 years warranty |
Specifications
* D.C Motor Controlled Automatic A.C Voltage Stabilizer
|
|
Single Phase |
Three Phase |
|
Input voltage |
±7% to ±32% of rated input supply |
±7% to ±32% of rated input supply |
|
Capacity |
2KVA to 30KVA |
6KVA to 100KVA |
|
Output voltage |
220 ± 1.5% |
380 ± 1.5% |
|
Frequency |
49Hz ÷ 62Hz |
49Hz ÷ 62Hz |
|
Phase |
Single Phase + N + GND |
Three Phase + N + GND |
|
Performance |
95% |
95% |
|
Insulation resistance |
More than 20MΩ |
More than 20MΩ |
|
Di-electric Strength |
1500V for 1Minute |
1500V for 1Minute |
|
Ambient Temperature |
Upto 50oC |
Upto 50oC |
|
Display Mode |
Voltmeter Analog |
Voltmeter Analog |
|
Input / Output Setting |
Plug / Socket |
Plug / Socket |
|
Output Short Circuit Protection |
Fuse / Breaker |
Fuse / Breaker |
|
Waveform Distortion |
No additional waveform distortion |
No additional waveform distortion |
|
Relative Humidity |
95% |
95% |
